型号: CYS-BLS0400
描述：50Kg大扭矩全金属无刷数字舵机 适用RC模型/无人机
尺寸: 40*20*33.5mm
扭力 :30Kg.cm ~ 50Kg.cm
速度: 0.019sec ~ 0.115sec/60 °
电压 : 5.0Volts ~8.4Volts
重量: 72g±1g
| Item No. | CYS-BLS0400 |
| Size | 40*20*33.5mm |
| Weight | 72±1g |
| Operating speed (at no load)@5.0V | 0.19sec/60° |
| Operating speed (at no load)@8.4V | 0.115sec/60° |
| Stall torque @5.0V | 30kg.cm |
| Stall torque @8.4V | 50kg.cm |
| Running current | 120mA |
| Stall current @5.0V | 6A |
| Stall current @8.4V | 9.4A |
| Idle Current | 10mA |
| Connector wire length | 320±5mm |
| Operating Voltage Range | 5.0V～8.4V |
